Smart IP Camera

Wi-Fi Battery Camera

Overview

The Wi-Fi battery camera solution liberates users from the hassle of wiring for power, allowing installation anywhere within Wi-Fi coverage. In low-power states, it maintains cloud connectivity with extremely low power consumption. Upon waking, it uploads video streams to the cloud rapidly with ultra-high throughput.

Tiered Low-Power Strategy: µA-Level Battery Life & Multi-Source Smart Wake-up

Wi-Fi Battery Camera Tiered Low-Power Strategy

Ultra-Low Power Cloud Keep-Alive: Customized low-power Wi-Fi keep-alive mechanisms maintain an average power consumption below 100µA while connected to the cloud, significantly extending battery life for months of recharge-free operation.
Deep Sleep for Ultimate Energy Saving: Supports deep sleep mode in idle scenarios, cutting power to non-core peripherals with an average power consumption below 12µA to maximize energy efficiency.
Flexible Multi-Source Wake-up Mechanism: Supports multiple wake-up sources including Wi-Fi Wake-up (triggered by cloud commands), GPIO Wake-up (triggered by external PIR sensors/door contacts), and Timer Wake-up (triggered by scheduled checks). It switches to active mode in milliseconds, balancing low power consumption with real-time monitoring.

Wi-Fi Dual-Band High-Speed Engine: Seamless HD Video Upload

40Mbps + Ultra-High Throughput: Supports 802.11n/ac standards with verified video stream upload speeds stably exceeding 40Mbps. It easily handles 1080p@30fps or higher bitrate real-time video transmission, ensuring clear, smooth, and stutter-free footage.
2.4G/5G Smart Dual-Band Adaptation: 2.4GHz offers strong penetration for stable long-distance connections; 5GHz provides low interference and high bandwidth for low-latency HD video transmission. The system automatically switches to the optimal frequency band based on signal quality and network load, perfectly balancing "wide coverage" and "high speed."
Multi-Scenario Adaptation Optimization: Packet strategies are customized for monitoring scenarios to balance transmission efficiency and power consumption, achieving the optimal solution between HD quality and low-power operation.

End-to-End Security Protection: Privacy Guard from Chip to Cloud

Chip-Level Root of Trust Security: Supports Secure Boot mechanisms to reject malicious firmware tampering; integrates TrustZone hardware isolation technology to run sensitive data and applications in independent partitions, building a solid security defense from the bottom up.
Wireless Transmission Encryption Upgrade: Fully supports the latest WPA3 Wi-Fi encryption protocol, significantly improving resistance to brute-force attacks compared to traditional methods, preventing eavesdropping or tampering of monitoring data during transmission.
End-to-End Network Encryption: Built-in TLS/SSL network security protocol stack enables two-way identity authentication and data encryption between the camera and the cloud server, ensuring surveillance footage privacy remains uncompromised and meets commercial-grade security standards.

Advantages

Ultra-Low Power Consumption

Power consumption is below 100uA in cloud keep-alive scenarios
Millisecond-level switching between low-power states
Microsecond-level peripheral wake-up latency, and millisecond-level Wi-Fi wake-up latency

Host System Diversity

The host driver supports Linux/FreeRTOS/Zephyr systems

Diverse Transmission Interfaces

Supports high-speed communication with the host via interfaces such as SDIO/USB/SPI

Development Resources

Icon	Resource Name	Link
	SDK Download	Link
	Wi-Fi Card Mode Development Guide	Link
	Low Power Development Guide	Link
	Contact Us	Link

Recommended ICs

Features	Filter	RTL8721Dx	RTL8720E	RTL8710E	RTL8726E	RTL8713E	RTL8730E	RTL8721F	RTL872xD	RTL8735B
Application Processor	Cortex-M Cortex-A	Cortex-M	Cortex-M	Cortex-M	Cortex-M	Cortex-M	Cortex-A	Cortex-M	Cortex-M	Cortex-M
DSP	Select
ISP?	Select
Arm TrustZone	Select
Dual Band?	Select
Wi-Fi 6	Select
R-MESH?	Select
Ultra-low Power	Select
Ethernet	Select
BT Dual Mode	Select
HMI?	Select
Audio ADC?	Select
Audio DAC?	Select
SDIO Host	Select
SD/EMMC Host	Select
USB	Select
BT Dedicated Antenna?	Select
CAN?	Select
